Nickel-iron alloys

Nickel-iron alloys are characterized by relatively high permeability, low core losses and low residual magnetism.

Their overall high saturation flux density means high-performance energy storage and transfer over low to middle frequencies. They can be used as a magnetic core material in electrical and electronic equipment and also in magnetic shielding applications. We can offer these alloys in precision wire, either round or flat, from diameters between 0.05mm and 12mm.

With our experience in this field, together with our partner JLC, we can provide the expertise to our customers on how to process these alloys as well as material selection and characteristics.

From 0.05mm to 12.0mm (round)

From 0.05mm (flat)    Up to 6mm    Temperature
Compensating Alloys:
Ni30Fe
Ni31Fe
Ni32Fe

High Permeability Alloys:
SMA 48 (Ni48Fe)
SMA 50 (Ni50Fe)
SMA 80 (Ni80Mo5Fe)

2   HAZARDS IDENTIFICATION

GHS Classification (29 CFR 1910.1200):   Not classified as hazardous

GHS Label Elements:

Signal Word: N/A

Hazard Statements: N/A

Precautionary Statements:   N/A

3   COMPOSITION/INFORMATION ON INGREDIENTS

Ingredient:       CAS#:              %:              EC#:

Nickel                 7440-02-0       50-99           231-111-4

Iron                   7439-89-6         1-50           231-096-4
